20 years manufacturer of hospital furniture

Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 1
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 2
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 3
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 4
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 5
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 6
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 1
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 2
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 3
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 4
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 5
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 6

Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5°

Model:
YXZ-C5(A1B)
Inquiry
Trendelenburg & Reserve-Trendelenburg
0-12°
Knee section adjustment range
0-35°±10°
Back section adjustable from
0-65°±5°

Product details of the high low hospital bed


Product Specification

Trendelenburg & Reserve-Trendelenburg: 0-12°

Knee section adjustment range: 0-35°±10°

Back section adjustable from: 0-65°±5°


Product Overview

Each production procedure of high low hospital bed is well-controlled by professional QC team. The product is of reliable quality as it is produced and tested based on the requirements of widely-recognized quality standards. high low hospital bed of is widely used and has a wide range of applications. To provide quality services to domestic and foreign merchants is constant pursuit.


Product Description

Our high low hospital bed is more competitive than similar products, as shown in the following aspects.

Introduction

It is a High level ICU bed, widely used in intensive care room. The bed is specialized equipped with column type motor, and left and right tilt function can be reached in this bed. Power, nurse call, alarm signal and weight scale is connected on this bed. we also equipped one back-up battery with this bed in case of power failure.


There is manual and electric CPR function with our bed. We also offer different function of mattress together with the bed like high density pure foam mattress and anti-bedsore mattress. We are committed to provide patients and nursing staff the most comprehensive and fastest beds, to avoid any accident.

7 function electric bed-2
External Length 2275mm± 20mm
External width 1080mm± 20mm
Height adjustment range (510-910mm)± 20mm
Mattress platform size L1960*W900mm± 10mm
Backrest section adjustment range 0-65°±5°
Knee section adjustment range 0-35°±10°
Leg section adjustment range 0-40°±5°
Trendelenburg & Reserve-Trendelenburg 0-12°
Left& Right tilt angle 0-17°
7 function electric bed-4

Configuration List

Bumper wheels: 4pcs

Central-control castors: 4pcs

Sockets of I.V. Pole: 4pcs

Stainless steel I.V. Pole with 4 hooks: 1pc

Movable ABS drainage hooks: 6pcs

Anti-Bedsore mattress: 1pc

Side rails: 4pcs

Foot board remote control: 1pc

Hand-held remote control: 1pc

Angle indicator: 2pcs

Back-up Battery: 1pc

Features

electrci hospital bed-4
Casters
Double-sideφ150mm luxury castors, center braking system on both side.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 10
Bumper Wheels
Detachable bumper wheel ,protect bed and patient during transportation.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 11
Double layer column
Bed+ integral base+ column (safe static load ≥ 200kg, safe working load of bed ≥ 150kg)
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 12
Bed surface
Bed surface is made of cold-rolled steel plate. Plastic mattress stop, non slip.
electrci hospital bed-4
Electric Motor
DC safety voltage motor drive system and control box. Product protection grade: IPX4. Average operation time ≥ 8000hours.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 14
Head and Foot board
Size:≥ 940 * 535mm. Distance between head &foot board and bed surface: 470mm, 3 hollow positions. Color customized available.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 15
Segmented side rail
Side rails distance: ≤ 60mm Distance between side rail and head and foot board: ≤ 60mm Distance from top to bed : 350mm Color customized available.
7 function electric bed-6
Nursing remote control
1.Beautiful appearance with completely independent design. 2.Various functions can be operated, especially weighing system.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 17
Bed surface back plate
Abdominal decompression and automatic regression function
electrci hospital bed-5
Electric/manual CPR
Electric CPR is operated by one button. Manual CPR can be operated by one hand in case of insufficient power.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 19
Weighing function
Weighing range: 0-150kg (accuracy ≤ 0.2kg); Power off protection function and patient leaving bed alarm function.
Custom High Low Hospital Bed YXZ-C5(A1B) 0-65°±5° 20
Foot board nursing remote control
1.Beautiful appearance with completely independent design. 2.Various functions can be operated, especially weighing system. 3.Touch switch with better feeling.

Product Details

7 function electric bed-6
7 function electric bed-6
7 function electric bed-8
7 function electric bed-8


Company Advantages

is located in We run the key business of upholds the value of 'high-quality service, high-tech innovation, high-speed development'. We seek excellence based on laborious efforts and dedication. We constantly pursue progress and development, so as to provide professional and distinctive services. has formed a team of professional and technical talents, and the whole team requires high standards and high production efficiency. has many years of industry experience and strong production strength. According to different needs of customers, we are able to provide customers with excellent and efficient one-stop solutions.
We hope to cooperate with you for a win-win situation and jointly create a better future.
