Standard Regulations and Best Selection Scheme of AC / DC Power Supply in Medical Equipment
Power supply standardIEC 60601-1:2005 and accompanying documents specify the safety and basic functional requirements of the power supply. The standard appears in the form of ANSI / AAMI document in the United States and in the form of "euronorm" in Europe and around the world, with some local differences. Since January 2021, the latest revision (a1:2012, a2:2020) has updated the standard, deleted outdated references, corrected errors and made it better consistent with IEC 62368-1. The current medical EMC standard IEC 60601-2 is the 4th Edition.Built in medical power standard
AC powered medical devices can have "built-in" power supplies or lower power external adapters. If it is an internal product, the product designer should consider high voltage and high energy, and usually choose to buy a "medically certified" power supply. However, the final product is the product certified for this application, so there are other considerations, such as labels, connectors, internal wiring of power supply and fuses.
Due to grounding, external wiring and interference from other noise sources, the built-in power supply conforming to EMC standards cannot be guaranteed to pass the test. A common practice is to add another EMI filter at the AC inlet, which may be included in the connector. However, it should be noted that the leakage current limit should not be exceeded. For the most stringent CF product rating, the leakage current limit can be as low as 10 a. The leakage of external filter may directly lead to the internal leakage of AC power supply, there is a risk of interaction between external filter and internal filter, and may even worsen EMI.
Secure power solutionsThe safe solution should select the target application and specify a power supply with 2 x MOPP certification and EMC compatible performance. For example, power supplies from recom racm230-g, racm550-g and the recently released racm-1200v series.Their peak or rated power is 230W, 550W and 1200W respectively. When fans are not allowed (usually in medical environments), these products can be floor cooled. All products have 2x MOPP / 250V AC rating to prevent leakage to ground (racm550 / 1200). The safety barrier in each recom power supply is shown in Figure 2.
Figure 2: safety fence racm230 / 550 / 1200 seriesFigure 3: a 2x MOPP DC / DC converter provides SIP / SOP isolationUsing a medically certified power supply (such as the power supply of recom) is a reliable way to ensure that the safety and EMC standards required by various medical application environments are met. It would be a lower overall cost approach if development, certification costs and time to market were taken into account.
Recom is a good choice when selecting AC / DC power supply for medical equipment. Eurotime electronics, as a distribution partner of recom, provides local inventory and technical support.Original title: eurotime classroom | AC / DC power supply in medical applicationsThe source of the article: WeChat official account: Euro time electronic RS] welcome to add attention! Please indicate the source of the article.
